Key Features
Up to OD6+ blocking
Fully custom designs
Made to order
Hard dielectric thin film coatings
Durable Quadrode™ plasma PVD technology
5–10 nm per mm dispersion rate
Up to 95% average transmission
355–1600 nm wavelength range
Technical Specifications
SPECIFICATION
PARAMETER
Center Wavelength (CWL)
355–1600 nm standard; custom available
Blocking
Up to OD6+
Transmission
Up to 95% average
Coating Type
Hard dielectric coatings utilizing Quadrode™ plasma PVD technology
Substrate Materials
Borofloat, Fused Silica, BK7, Custom
Surface Quality
60-40 scratch-dig
Configuration
Rectangle, 50 x 10mm typical
Custom CWL / Sizing
Available on request
Environmental
Please contact for full environmental specifications
