OD6 Notch Filters

OD6+ blocking

At laser wavelength

Fully custom designs

Made to order

Hard dielectric thin film coatings

Durable Quadrode™ plasma PVD technology

Bandwidth (FWHM) 2.5% of CWL or greater

Up to 95% average transmission

Available mounted or unmounted

SPECIFICATION

PARAMETER

Center Wavelength (CWL)

355–1064 nm standard; custom available

Blocking

OD6+

Transmission

Up to 95% average

Blocking Bandwidth (FWHM)

2.5% of CWL or greater

Coating Type

Hard dielectric coatings utilizing Quadrode™ plasma PVD technology

Substrate Materials

Borofloat, Fused Silica, BK7, Custom

Surface Quality

60-40 scratch-dig

Clear Aperture

>85% of diameter on mounted parts

Configuration

Mounted or unmounted

Custom CWL / Sizing

Available on request

Environmental

Please contact for full environmental specifications

Full Specifications
