Key Features
Up to OD6+ blocking
Fully custom designs
Made to order
Hard dielectric thin film coatings
Durable Quadrode™ plasma PVD technology
Mounted or unmounted
Up to 95% average transmission
60-40 scratch-dig
Technical Specifications
PARAMETER
SPECIFICATION
Center Wavelength (CWL)
300–1800 nm standard
Blocking
Up to OD6+
Transmission
Up to 95% average
Blocking Type
Multi-band notch
Coating Type
Hard dielectric coatings utilizing Quadrode™ plasma PVD technology
Substrate Materials
Borofloat, Fused Silica, BK7, Custom
Surface Quality
60-40 scratch-dig
Clear Aperture
>85% of diameter on mounted parts
Configuration
Mounted or unmounted
Custom CWL / Sizing
Available on request
Environmental
Please contact for full environmental specifications
